Features

Expert II Series is the best choice for beginners and provides sign makers with optimum speed, superior quality, solid reliability and unmatched value. Expert II produces eye-catching graphics with up to 27.8 ips (25 ips for EX-52 models ) cutting speed, 350g of cutting force and three meters (9.84 feet) of tracking ability. The versatile Expert II Series sets a new benchmark for value, offering high accuracy and reliability at an unbelievably affordable price.

SPECIFICATIONS

Expert II Series EX II-24LX EX II-52LX
Max. Cutting Width 600 mm (23.6 in.) 1320 mm (51.96 in)
Max. Media Width 719 mm (28.3 in.) 1635 mm (64.37 in.)
Acceptable Material Thickness 0.8 mm
Cutting Force 350 g
Max. Cutting Speed 705 mm/sec (27.8 ips)
(at 45 degree direction)
635 mm/sec (25 ips)
(at 45 degree direction)
Mechanical Resolution 0.009 mm (0.00035 in.) 0.012 mm (o.ooo49 in.)
Software Resolution 0.025 mm (0.00098 in.)
Distance Accuracy ±0.254 mm or ±0.1% of move, whichever is greater
Repeatability ±0.1
Mechanical Resolution 0.006 mm
Tracking 3M
Memory Buffer 32 MB / 16 MB (when using AAS)
Type of Command HPGL, HPGL/2
Configurable Origin Yes
Repeat Yes
Copy Yes
Control Panel 6 LEDs / 10 Keys
Diameter of Blade 2.5 mm
Dimension (HxWxD) mm 233*255*880 1065*1632*620
Dimension (HxWxD) in 9.1*10*34.6 41.93*62.25*24.41
Net Weight 11KG (24.3lb) 41KG (90.4lb)
Stand Optional Standard
Automatic-Aligning System (AAS II) Available on Expert II LX models
Power Supply 100-240 VAC, 50 / 60 Hz (auto switching)
Power Consumption Max. 288 W
Operation Environment Temperature 15° C~30° C / 60°F~86° F
Humidity 25% ~ 75%
