This first hydraulic type of double plate transfer printing machine is the most suitable machine for transfer printing of cut pieces fabric. There are two commutable plates which not only reduce the occupying area of the machine, but also improve the working efficiency.
The high quality blanket it used could buffer and keep heat during working. The hydraulic elevating system ensures that the pressure is always maintained stable and reduction of noise pollution; it also can ensure that the patterns of printed fabric are precise, vivid and even.
| Model No. | FB-1012 | FB-1015 | FB-1217 |
| Suitable Media | Garments, Ski board, metal board, seat pad, shoe pad | ||
| Power Supply | 3phases, 220V/380V/480V | ||
| Power | 14.5kw | 18kw | 24kw |
| Transfer Media | Heating plate & Electric | ||
| Max Temperature | 260°C | ||
| Heat Type | Single Side Heating | ||
| Working Size | 1000 x 1200mm | 1000 x 1500mm | 1200 x 1700mm |
| Machine Size | 2300 x 1500 x 1580mm | 2300 x 1800 x 1580mm | 2500 x 2000 x 1580mm |
| Packing Size | 2500 x 1700 x 1850mm | 2500 x 2000 x 1850mm | 2500 x 2200 x 1850mm |
| Net Weight | 950kg | 1150kg | 1500kg |
